Description
Normative Standard Reference
- Design Standard: API 609 | IS 13095 | BS 5155
- Face to Face: API 609 | IS 13095 | BS 5155
- Testing Standard: API 598 | ISO 5208
- Pressure Rating: PN10 | PN16
- End Connection: Wafer to suite ANSI 150 Class, BS Table D & E | DIN PN 10 & 16
Material of Construction
- Body: CI | SG | WCB | CF8 | CF8M etc
- Disc: SG | CF8 | CF8M | Nylon Coated | Al Bronze
- Disc: Nitrile | EPDM | Viton | Silicon | Hypalon | etc
- Shaft: SS 410 | 304 | 316 | etc
- Operation: MS, SG, Al Handle | Pneumatical Actuation Motorised | Limit & Tamper Switch Fitted
Key Features
- Low torque resulting in low wear & long life
- Molded & Replaceable seat options available
- Easy to assemble & dismantle in replaceable seat
- Top flange as per ISO 5211 for easy actuation
- Full Bore gives high Cv
- WCB & SS is Investment Casted Body upto 200mm
